LevelOne OSW-1031 network switch Unmanaged 2.5G Ethernet (100 1000 2500) Power over Ethernet (PoE) Black
  • LevelOne OSW-1031 network switch Unmanaged 2.5G Ethernet (100 1000 2500) Power over Ethernet (PoE) Black
  • LevelOne OSW-1031 network switch Unmanaged 2.5G Ethernet (100 1000 2500) Power over Ethernet (PoE) Black
  • LevelOne OSW-1031 network switch Unmanaged 2.5G Ethernet (100 1000 2500) Power over Ethernet (PoE) Black

LevelOne OSW-1031 network switch Unmanaged 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Black

37C04569

LevelOne OSW-1031, Unmanaged, 2.5G Ethernet (100/1000/2500), Full duplex, Power over Ethernet (PoE)

€420.00
Tax included
Quantity
Articolo in magazzino

NB. Per richiesta fattura compilare i campi Partita IVA o CODICE FISCALE presenti in fase di conferma ordine.

Buy it now and receive it between 9/22/25 and 9/25/25 with Corriere Espresso

Description
LevelOne OSW-1031. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 4000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z. Power connector: DC-in jack. Power over Ethernet (PoE)
Switch typeUnmanaged
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports type2.5G Ethernet (100/1000/2500)
Installed SFP modules quantity0
2.5G Ethernet (copper) ports quantity8
SFP+ module slots quantity2
Power connectorDC-in jack
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X
Full duplexYes
Half duplexYes
Flow control supportYes
Auto MDI/MDI-XYes
Ethernet LAN data rates1000 Mbit/s
Auto-negotiationYes
MAC address table4000 entries
Switching capacity20 Gbit/s
Jumbo frames supportYes
Jumbo frames9000
Packet buffer memory12 MB
Rack mountingNo
StackableNo
Product colorBlack
LED indicatorsLink, Power
International Protection (IP) codeIP55
FanlessNo
Mean time between failures (MTBF)4000000 h
Power sourceAC
Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power consumption (max)120 W
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity8
Total Power over Ethernet (PoE) budget115 W
Operating temperature (T-T)-20 - 65 °C
Storage temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 90%
Width11" (280 mm)
Depth7.87" (200 mm)
Height9.84" (250 mm)
Weight17.6 lbs (8 kg)
Quick start guideYes
ManualYes
Package typeBox
Compliance certificatesCE, Federal Communications Commission (FCC)
Product Details
LevelOne
37C04569
5 Items

Specific References

EAN13
4015867236437
