Intel Core i7-13700F processor 30 MB Smart Cache Box

Intel Core i7-13700F. Processor family: Intel® Core™ i7, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 5.0, 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz. Package type: Retail box

Processor family	Intel® Core™ i7
Processor cores	16
Processor socket	LGA 1700
Box	Yes
Cooler included	Yes
Processor manufacturer	Intel
Processor model	i7-13700F
Processor operating modes	64-bit
Processor generation	13th gen Intel® Core™ i7
Processor threads	24
Performance cores	8
Efficient cores	8
Processor boost frequency	5.2 GHz
Performance-core boost frequency	5.1 GHz
Performance-core base frequency	2.1 GHz
Efficient-core boost frequency	4.1 GHz
Efficient-core base frequency	1.5 GHz
Processor cache	30 MB
Processor cache type	Smart Cache
Processor base power	65 W
Maximum turbo power	219 W
Bus type	DMI4
Maximum number of DMI lanes	8
Memory bandwidth supported by processor (max)	89.6 GB/s
Processor codename	Raptor Lake
Processor ARK ID	230491
Memory channels	Dual-channel
Maximum internal memory supported by processor	192 GB
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
Non-ECC	Yes
Memory bandwidth (max)	89.6 GB/s
On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Use conditions	PC/Client/Tablet
Maximum number of PCI Express lanes	20
PCI Express slots version	5.0, 4.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
CPU configuration (max)	1
Embedded options available	No
Direct Media Interface (DMI) Revision	4.0
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Max Technology 3.0 frequency	5.2 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Thread Director	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Secure Key	Yes
Intel® OS Guard	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Boot Guard	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® Volume Management Device (VMD)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Standard Manageability (ISM)	Yes
Tjunction	100 °C
Harmonized System (HS) code	8542310001
Package type	Retail box
Processor package size	45 x 37.5 mm
L2 cache	24576 KB
Maximum internal memory	192 GB
Target market	Gaming, Content Creation
Launch date	Q1'23
Status	Launched
