Intel Core i3-9100 processor 3.6 GHz 6 MB Smart Cache Box

Intel Core i3-9100. Processor family: Intel® Core™ i3, Processor socket: LGA 1151 (Socket H4), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel® UHD Graphics 630, On-board graphics card memory: 64 GB, Maximum on-board graphics card memory: 64 GB. Market segment: Desktop, PCI Express configurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 4.2 GHz

Processor family	Intel® Core™ i3
Processor cores	4
Processor socket	LGA 1151 (Socket H4)
Processor lithography	14 nm
Box	Yes
Cooler included	Yes
Processor manufacturer	Intel
Processor model	i3-9100
Processor base frequency	3.6 GHz
Processor operating modes	64-bit
Processor generation	9th gen Intel® Core™ i3
Component for	PC
Processor threads	4
System bus rate	8 GT/s
Processor boost frequency	4.2 GHz
Processor cache	6 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	65 W
Memory bandwidth supported by processor (max)	37.5 GB/s
Processor codename	Coffee Lake
Processor ARK ID	134870
Memory channels	Dual-channel
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
ECC	Yes
On-board graphics card	Yes
Discrete graphics card	No
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card model	Not available
On-board graphics card memory	64 GB
Maximum on-board graphics card memory	64 GB
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Number of displays supported (on-board graphics)	3
On-board graphics card 4K support	Yes
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card maximum resolution (DisplayPort)	4096 x 2304 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	24 Hz
On-board graphics card ID	0x3E91
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
CPU configuration (max)	1
Embedded options available	No
Thermal solution specification	PCG 2015C
PCI Express CEM revision	3.0
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	No
Intel® Memory Protection Extensions (Intel® MPX)	Yes
Intel® Turbo Boost Technology 2.0 frequency	4.2 GHz
Intel® Transactional Synchronization Extensions	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Secure Key	Yes
Intel TSX-NI	No
Intel Stable Image Platform Program (SIPP)	No
Intel® OS Guard	Yes
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Optane™ Memory Ready	Yes
Intel® Boot Guard	Yes
Intel® vPro™ Platform Eligibility	No
Tjunction	100 °C
Product type	Processor
Supported memory types	DDR4-SDRAM
Maximum graphics card memory	64 GB
Harmonized System (HS) code	85423119
Package width	2.76" (70 mm)
Package depth	4.57" (116 mm)
Package height	3.98" (101 mm)
Package weight	11.9 oz (338 g)
Package type	Retail box
Processor package size	37.5 x 37.5 mm
Maximum internal memory	64 GB
Generation	9th Generation
Launch date	Q2'19
Maximum resolution & refresh rate (DisplayPort)	4096 x 2304@60Hz
Status	Launched
Maximum memory	64 GB
Bus speed	8 GT/s
Processor ID	0x3E91
