Intel Core i7-9700T processor 2 GHz 12 MB Smart Cache

Intel Core i7-9700T. Processor family: Intel® Core™ i7, Processor socket: LGA 1151 (Socket H4), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel® UHD Graphics 630, Maximum on-board graphics card memory: 64 GB, On-board graphics card base frequency: 350 MHz. Market segment: Desktop, PCI Express configurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 4.3 GHz

Processor family	Intel® Core™ i7
Processor cores	8
Processor socket	LGA 1151 (Socket H4)
Processor lithography	14 nm
Box	No
Cooler included	No
Processor manufacturer	Intel
Processor model	i7-9700T
Processor base frequency	2 GHz
Processor operating modes	64-bit
Processor generation	9th gen Intel® Core™ i7
Component for	PC
Processor threads	8
System bus rate	8 GT/s
Processor boost frequency	4.3 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	35 W
Configurable TDP-down frequency	1.5 GHz
Configurable TDP-down	25 W
Memory bandwidth supported by processor (max)	41.6 GB/s
Processor codename	Coffee Lake
Processor ARK ID	191048
Memory channels	Dual-channel
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
ECC	No
On-board graphics card	Yes
Discrete graphics card	No
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card model	Not available
Maximum on-board graphics card memory	64 GB
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
On-board graphics card 4K support	Yes
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card maximum resolution (DisplayPort)	4096 x 2304 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	24 Hz
On-board graphics card ID	0x3E98
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
CPU configuration (max)	1
Embedded options available	No
Thermal solution specification	PCG 2015A
PCI Express CEM revision	3.0
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® Memory Protection Extensions (Intel® MPX)	Yes
Intel® Turbo Boost Technology 2.0 frequency	4.3 GHz
Intel® Transactional Synchronization Extensions	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Secure Key	Yes
Intel TSX-NI	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel® OS Guard	Yes
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Optane™ Memory Ready	Yes
Intel® Boot Guard	Yes
Intel® vPro™ Platform Eligibility	Yes
Tjunction	100 °C
Product type	Processor
Supported memory types	DDR4-SDRAM
Maximum graphics card memory	64 GB
Harmonized System (HS) code	8542310001
Processor package size	37.5 x 37.5 mm
Maximum internal memory	128 GB
Generation	9th Generation
Launch date	Q2'19
Maximum resolution & refresh rate (DisplayPort)	4096 x 2304@60Hz
Status	Launched
Maximum memory	128 GB
Bus speed	8 GT/s
Processor ID	0x3E98
