TP-Link VIGI C540S(4mm) Turret IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling/wall

TP-Link VIGI C540S(4mm). Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product color: Black, White, Form factor: Turret. Lens viewing angle, horizontal: 104°, Lens viewing angle, vertical: 55°, Lens viewing angle, diagonal: 127°. Sensor type: CMOS, Optical sensor size: 1/3". Detect distance: 2480.3" (63 m), Observe distance: 1023.6" (26 m), Recognize distance: 511.8" (13 m)

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
PTZ control	Yes
PTZ modes	Auto scan, Preset point
Preset points	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Certification	CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
Mounting type	Ceiling/wall
Product color	Black, White
Form factor	Turret
Housing material	Plastic
International Protection (IP) code	IP66
Camera pan control	Yes
Camera tilt control	Yes
Lens viewing angle, horizontal	104°
Lens viewing angle, vertical	55°
Lens viewing angle, diagonal	127°
Tilt angle range	0 - 105°
Tilt speed	44 °/sec
Pan range	0 - 348°
Pan speed	44 °/sec
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/3"
Number of lenses	1
Detect distance	2480.3" (63 m)
Observe distance	1023.6" (26 m)
Recognize distance	511.8" (13 m)
Lens diameter	0.157" (4 mm)
Identify distance	236.2" (6 m)
Night vision	Yes
Night vision distance	30 m
LED type	IR
Maximum resolution	2688 x 1520 pixels
Total megapixels	4 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	320 x 240, 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Frame rate	30 fps
Video streaming	Yes
Image quality adjustment	Brightness, Contrast, DNR, Mirror, Saturation, Sharpness
Privacy masking	Yes
Bit rate	256 Kbps - 6 Mbps
Back Light Compensation (BLC)	Yes
Highlight Compensation (HLC)	Yes
Digital Wide Dynamic Range (DWDR)	Yes
Region of Interest (ROI) encoding	Yes
Built-in speaker(s)	Yes
Audio system	2-way
Audio input channels	1.0 channels
Audio output channels	1.0 channels
Built-in microphone	Yes
Bit rate range	0 - 64 Kbit/s
Sample rates	0 - 8 kHz
Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	No
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Live view	Yes
Number of simultaneous live view channels	3 channels
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Password protection	Yes
IP address filtering	Yes
HTTPS encryption	Yes
Intelligent Video Surveillance (IVS) system features	Abandoned object, Human detection, Vehicle detection
Mirror	Yes
Human and vehicle targets classification	Yes
Digest authentication	Yes
Web browser	Yes
Reset button	Yes
Behavior analysis	Intrusion detection, Line crossing detection, Region exiting detection
Smartphone remote support	Yes
Power source type	DC, PoE
Power consumption (max)	13.13 W
Power consumption (Power over Ethernet (PoE))	16.47 W
DC output voltage	12
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Width	4.72" (120 mm)
Depth	6.77" (172 mm)
Height	7.99" (203 mm)
Number of cameras	1
