MSI CUBI NUC AI 1UMG-018BEU, Mini PC, Mini PC barebone, Intel SoC, Ethernet LAN, Wi-Fi 6E (802.11ax), 120 W
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 7 |
| Processor generation | Intel® Core™ Ultra (Series 1) |
| Processor model | 155H |
| Processor cores | 16 |
| Processor threads | 22 |
| Processor boost frequency | 4.8 GHz |
| Performance cores | 6 |
| Efficient cores | 8 |
| Low Power Efficient-cores | 2 |
| Performance-core Max Turbo Frequency | 4.8 GHz |
| Efficient-core Max Turbo Frequency | 3.8 GHz |
| Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
| Performance-core base frequency | 1.4 GHz |
| Efficient-core base frequency | 0.9 GHz |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | M.2 |
| NVMe | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel Arc Graphics |
| Discrete graphics card model | Not available |
| Number of displays supported | 4 |
| Built-in speaker(s) | No |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| LAN controller | Intel I226-V |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| HDMI ports quantity | 2 |
| VGA (D-Sub) ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| DVI port | No |
| DisplayPorts quantity | 0 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Thunderbolt 3 ports quantity | 0 |
| Thunderbolt 4 ports quantity | 2 |
| DC-in jack | Yes |
| Number of M.2 (M) slots | 2 |
| Chassis type | Mini PC |
| Product color | Black |
| Cooling type | Active |
| Product type | Mini PC barebone |
| Housing material | Plastic |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Motherboard form factor | NUC |
| Motherboard chipset | Intel SoC |
| Number of processors supported | 1 |
| Optical drive type | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Certification | FCC(Class B), CB/CE, UL(CUL), BSMI, VCCI, RCM(C-Tick) |
| Operating system installed | No |
| Power supply type | External AC adapter |
| Power supply | 120 W |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 90% |
| Width | 4.71" (119.6 mm) |
| Depth | 4.54" (115.2 mm) |
| Height | 1.48" (37.5 mm) |
| Weight | 22.2 oz (630 g) |
| Package width | 8.07" (205 mm) |
| Package depth | 8.66" (220 mm) |
| Package height | 3.7" (94 mm) |
| Package weight | 3.2 lbs (1.45 kg) |
| Power cord included | Yes |
| AC adapter included | Yes |
| Display included | No |
| Mouse included | No |
| Keyboard included | No |
| Warranty period | 3 year(s) |
